CheckMate™ Pivot Bolts with 5/16" Threads

Product Code: piv-516

Description: 3/8" x 3/4" Pivot Bolt

Threads: 5/16"

Shoulder Length: 3/4"

Shoulder Thickness: 3/8"

Sold In Pairs: (2)

Includes: 3/8" Locking Collars, 3/8" Flat Washers, Nylon Washers & Nylon Lock Nuts

Mowers Supported:

Husqvarna HU Series

Husqvarna LC Series

Toro Recycler (2021 and Newer)

Toro Super Recycler

Toro TimeMaster

Note: Lawn Striping Kit Only / Mower Sold By Your Local Retailer

$7.00

3 Year
Warranty 30 Day
Money Back Fast
Shipping

Product Features

Rugged frame and casters

Constructed from the toughest of materials, the CheckMate™ is manufactured from high density injection molded rubber and 12 gauge powder coated steel.

Free Floating

All CheckMate striping kits have a unique connection method which utilizes a pivoting action. This allows significant weight to be placed on the turf while allowing the roller to freely float up and down over the contours of the lawn.

Reinforced mounting hardware

All mounting hardware is reinforced with heavy duty galvanized flat stock steel measuring 1/4” in total thickness.

Maintenance - Free

All CheckMate™ striping kits deliver worry free operation. Dual flanged nylon bushings are utilized in each caster for superior operation in dirty and corrosive environments.

Installation

Specifications

Rollers

Construction

Solid injection molded

Size

5" Commercial / 4" Residential

Bushings

Dual Flange Nylon

Treaded

Provides extended life

Steel

Slide Rail

Provides infinite connection points

Slide Rail Construction

12 gauge; powder coated

Mounting Plates

1/4" flat stock; galvanized

Mounting Hardware

1/2" Grade 5; galvanized

Features

Connection Point

Free Floating; Continuous compression

Individual Rollers

Reduces friction on zero radius turns

Product Warranty

Big League Lawns, LLC warrants their products to be free of defects in material and workmanship. This warranty does not cover defects due directly or indirectly to misuse, abuse, normal wear and tear, failure to properly maintain the product or used for a purpose other than which it is intended. The duration of this warranty is expressly limited to one year parts and labor beginning from the date of delivery to the original user. The obligation of Big League Lawns, LLC is limited solely to the repair or replacement, at our option, at its factory or authorized repair agent of any part that should prove deficient. Purchaser must maintain the product under normal operating conditions at all times. Prior to operation, become familiar with the features of the attachment. This product is not intended to be used in a transport position or to be backed over curbs. Failure to follow these instructions will void the warranty.
